EA45 portable car fridge

EA series car refrigerator,originally with single zone design.It can be updated to a dual zone with a solid partition.So it can meet different temperature demand.The temperature difference between the two zones is about 10~20℃ according to setting temperature and ambient temperature.It is widely used by RV users, campers, truckers, boat owners.

Features:

1) Fast Freeze to -20℃

2) Single / dual zone adjustable

3) 3 size available:35L,45L,55L

4) Pull wheel optional

5)Customized color

Product parameters

Model	Description
EA45 car fridge	Product size(mm)	726390443
	Packing size(mm)	710445525
	Color	Orange + blackWhite + blackGrey + black
	N.W.(KG)	14.1
	G.W.(KG)	16.5
	Refrigerant	R134a(R600a optional)
	Cooling range	-20℃ ~+10℃ （32℃ ambient temperature）
	Rated voltage	DC12V/24V (AC110V-240V)
	Rated power	45W(±20%)
	Noisel level	≤45dB
	Cooling method	Compressor
	Body material	ABS
	Loading ability	20FCL:168PCS; 40HQ:430PCS

Standard accessories

DC cable(for car use, connect on cigarette lighter)

AC adapter(for home use)

Optional accessories:

Inner basket

Application

This series car fridges are designed with popular size 35L,45L,55L,widely used in camping,picnic,fishing,trucking,both car and home use.With solid partition,you can see it as a dual zone car fridge,which help you put different food inside.If you feel it is a little heavy,you can pull it with the handle since it can add wheels on it.

Note:

1. When using the car refrigerator for the first time, clean the inside of the box and wipe off the excess water droplets.

2. The car refrigerator is the same as the household refrigerator. Magnetic and corrosive objects cannot be placed in the box.

3. The car refrigerator also has a cooling air outlet. Be careful not to block the air outlet when placing it.

4. It is best to be equipped with a power converter to achieve the correct use of the refrigerator at home and in the car.

5. Note that the inclination angle of the compressor car refrigerator should not exceed 30°, so as to avoid the compressor downtime.

6. When using the car refrigerator, you must read the instructions carefully to clearly understand the refrigeration temperature, working environment, voltage and other requirements of the car refrigerator.
